Model No. | KV | Rm | No-load | Max | Max Power | LiPo | Weight | Dimension | Shaft | Recommended | ESC |
RPM/V | ohms | Current(A) | Current(A) | Watt | Cell | g | Dia. x L.mm | diameter | Prop | A | |
iBM2212Q | 850 | 0.142 | 0.50 | 12.20 | 135 | 2-4S | 77 | 28x26 | 3.175mm | 10x4.5/10x4.5R | 20 |
iBM2217Q | 880 | 0.107 | 0.80 | 20.00 | 210 | 2-4S | 89 | 28x36 | 4.0mm | 12x4.5/12x4.5R | 30 |
iBM2814Q | 750 | 0.094 | 1.00 | 24.20 | 350 | 2-4S | 102 | 35x36 | 5.0mm | 10x7/11x4.7/12x5 | 40 |
iBM4006Q | 360 | 0.37 | 0.20 | 9.90 | 180 | 2-3S | 78 | 50x10 | 3.175mm | 15x8,14x8 | 12 |
