Serial No.

Item

Unit

Design Figure

1

Model

/

4LZ-2.5A

2

Structure Type

/

Vertical Axial-flow Feed Crawler Self-running Type

3

Engine

Manufacturer

/

Lion Engine

Model

/

LN498LZ

Structure Type

/

4-cylinder, vertical water-cooled,

Power

kW

52

Speed

r/min

2600

4

Overall Dimension (Length* Width* Height)

mm

5200X2420X2480

5

Machine Weight

kg

2980

6

Header Width

mm

2000

7

Feeding Amount

t/h

9

8

Minimal Ground Clearance

mm

240

9

Working Speed

km/h

0～5.0

10

One-hour Productivity

hm2/h

0.27～0.53

11

Fuel Consumption

kg/hm2

16～25

12

Cutter Type

/

Standard Ⅱ

13

Header Auger Type

/

Helical Rotating Blade Eccentric Telescopic

14

Reel

Type

/

Eccentric Spring Tooth Type

Diameter

mm

φ900

Quantity

Pcs

5

15

Threshing Drum

Quantity

Pcs

1

Type

/

Axial-flow Spike-tooth Type

Size (Outer Diameter* Length)

mm

φ620X1800

16

Escape Grid Type

/

Grid Type

17

Fan

Type

/

Centrifugal Type

Diameter

mm

φ400

Quantity

Pcs

1

18

Crawler

Size (pitch*section*width)

/

90mm*51sections*400mm

Guage

mm

1100

19

Gearbox Type

/

HST, Sub-transmission 3 Grade

20

Brake Type

/

Wet Friction Type

21

Rethresher  Type

/

Plank Tooth Type

22

Grain Collecting Method

/

Manual Grain Collecting/ Mechanical Self-unloading
