Model |
| 4YZ-6 G60 |
Feeding Quantity | Kg/ S | 6.0 |
The harvesting No. of rows |
| 6 |
Cutting Width | mm | 3660mm (4570mm paddy cutting table) |
Loss Rate | % | ≤1.5(Wheat, soybean) ≤3.0(Rice) |
Breakage Rate | % | ≤2.0(wheat, soybean) ≤2.0(Rice) |
Impurity rate | % | ≤2.0(wheat, soybean) ≤2.0(Rice) |
Productivity | Sqm / Hour | 6700-12000 |
Power | Hp | 170 |
Dimensions | mm | 7400*4050*3400 (3660 Cutting Table) 7400*4900*3400 (4570 Cutting Table) |
Seed Husking Plant Type |
| Grain lever or nail tooth |
Separation Plant Type |
| Board tooth type Single vertical axial flow cylinder |
Cleaning Unit Area | Sqm | 3.4 |
Separation Area | Sqm | 1.62 |
Cylinder Dimension (Width* Diameter) | mm | 1020*610 |
Cleaning Rate | % | >98 |
Min picking height | mm | 482 |
Max picking height | mm | 2330 |
Picker |
| combination of stubble-pulling roller and picker board |
Total weight | kg | 8530 |
Grain Tank Volume | Cubic Meter | 3.0 |
Adapt Spacing | mm | 650 |
Engine |
| YC6108ZT |
Fuel Consumption | kg/hm2 | 20-40 |
Walking Form |
| Wheel Type |
Walking Speed | Km/Hour | 1.05-19.7(Forward Gear)2.40—5.55(Reverse Gear) |
Operating Weight | Kg | 8500 |
