VCM Zpicture1

VCM Z

USD $0.00 / pc 1pc (MOQ)
FOB Price:
Negotiable | Get Latest Price
Order Quantity:
1 Set / Sets
Supply Ability:
1000 Set / Sets per Month
Port:
shanghai
Payment Terms:
T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Delivery Detail:
5 days
Hot in store
Product Details

The traditional Z-axis focusing module adopts voice coil motor or galvanometer structure, which has high load quality, slow response time and low dynamic performance. VCM Z-axis focusing module breaks through the traditional perspective optical path design scheme and greatly improves the dynamic performance of the Z-axis focusing module. The highly innovative Z-axis structure design greatly reduces the following error, making the dynamic performance of Z-axis and XY galvo match perfectly, and ensures that the scanning speed of the 3D galvanometer is not restricted by the dynamic performance of Z-axis.



Key Features Of Vcm Z



Use only reflective elements, reducing thermal lensing in high power applications



No complex mechanical structure, ensure the stability of long time operation



Modular design, easy to assemble



Highly innovative Z-axis structure design significantly reduces following error and perfectly matches z-axis dynamic performance to XY axis

Specifications Of Vcm Z


VCM Z

Input Beam Aperture(mm)

14

Output Beam Aperture(mm)

14

Stroke(mm)

±15(Focus range)

Tracking Error(ms)

≥0.15

Focus Speed(m/s)

up to 20m/s (f=160mm)

Repeatability (μm)

<1

Nonlinearity(%)

0.4

Long-Term Drift Over 8 hours (μm)

<6

Power Requirement

±15VDC, ≥3A

Digital Interface

XY2-100

Operation Temperature(℃)

25±10



Hansscanner provides galvo scan head, galvanometer scanner, galvo scanner laser and etc. If you want to know more, pleasecontact us.
