It adopts the engagement sleeve gear shifting, force and position combined regulation. It is large in wheel span and axle base, heavy in dead load, and desirable in chassis stability. Besides, it is equipped with safety anti-toppling shelf for optional assemblage.The YTO-304 tractor is equipped with wet disc brakes, ensuring desirable braking performance and high reliability. It adopts the planetary end transmission and double action clutches. It is applicable to paddy fields and dry farmlands.

Technical Specifications:

Engine
Type	Double-cylinder, vertical, water-cooled, four-stroke, direct injection diesel
model	ZN390T
Rated speed	r/min	2300
Transmission System
Speed range	km/h	2.37-31.03
Overall Dimension	mm	3392×1634×1477
Min. ground clearance	mm	250
Machine body
Tires, front / rear	6.50-16/11.2-24 or 7.50-16/11.2-28
Wheel base	mm	1777.5
Front wheel tread / Rear wheel tread	mm	1150-1450
Min. turning radius	m	4.06
Min. operating weight	kg	1740
PTO shaft type		Semi-independent
PTO shaft rotation speed	r/min	22.1/2300
