Tantalum strip, Tantalum sheet coil, Ta ribbon

inquiry

FOB Price:
Negotiable | Get Latest Price
Min.Order Quantity:
1 Set / Sets
Supply Ability:
1000 Set / Sets per Month
Port:
shanghai
Payment Terms:
T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Delivery Detail:
5 days

Material : Tantalum strip, tantalum sheet, tantalum ribbon, tantalum foil, Ta strip in coil(cold rolled) for deep drawing application.
Temper Condition: annealed
Purity   : 99.9%min conformity with ASTM B708 98 UNS R05400
Chemical composition :
            O           0.0300 %max
            C           0.0100 %max
            N           0.0100 %max
            H           0.0015 %max
            Fe         0.0100%max
            Ni          0.0100%max
            Si          0.0050 %max
            Mo         0.0200 %max
            W          0.0500 %max
            Nb         0.1000 %max
            Ta         Remainder (typically 99.96%)
Physical & Mechanical property :
            Tensile strength      207 MPa min. or 30 KSI.
            Yield strength         138 MPa min. or 20 KSI.
            Elongation              20%min.
Size available:
             Thickness 0.05 up to 0.09mm x Width up to 110mm max.
             in one continuous coil with three EB welding parts
             which will be marked or not at buyer's option.

            Thickness 0.1 up to 0.9mm x Width up to 350mm max.
            in one continuous coil with three EB welding parts
            which will be marked or not at buyer's option.
            e.g. 1 tantalum coil = 25kgs approx. for 0.18mm(±0.020) x 67mm(±0.50)x Random continuous length in spools.
Typical Sizes :

Thickness  Width  Width Length
    (MM)  (Inch)  R/L
Tailored3.1750.125     in spool
4.760.187
6.000.236
7.520.296
7.920.312
9.530.375
9.850.388
11.890.468
12.450.490
12.70.500
15.880.625
19.050.750
21.030.828
21.590.850
24.000.945
25.401.000
26.971.062
28.581.125
29.971.180
30.481.200
31.751.250
31.961.258
33.021.300
34.001.339
34.181.346
34.851.372
36.581.440
38.891.531
39.671.562
39.951.573
40.641.600
42.061.656
42.401.669
43.691.720
44.451.750
44.571.755
45.201.780
45.211.780
47.201.858
48.001.890
50.001.969
50.251.978
50.802.000
52.372.062
54.402.142
55.372.180
55.622.190
57.152.250
59.002.323
60.002.362
61.152.407
61.212.410
61.522.422
63.502.500
64.702.547
65.072.562
66.402.614
66.672.625
67.462.656
68.002.677
69.852.750
70.642.781
72.002.835
74.602.937
75.002.953
75.502.972
76.002.992
76.203.000
76.253.002
80.003.150
81.753.219
82.003.228
82.553.250
85.003.346
87.003.425
90.003.543
92.003.622
92.003.622
94.003.701
95.003.740
1003.937
1003.937
1013.976
1024.000
1084.260
1204.724
1204.724
123.204.850
1264.961
1275.000
1305.118
1305.118
137.905.429
1405.512
1505.906
152.406.000
1706.693
1807.087
2007.874
2108.268
2409.449
30512.00

Standard Specification ASTM B 708 -05 for Tantalum Ribbon, Tantalum Alloy Ribbon, Tantalum Strip, Tantalum Alloy Strip, Tantalum Foil, Tantalum Alloy Foil, Tantalum Sheet, Tantalum Alloy Sheet, Tantalum Plate, Tantalum Alloy Plate.

This specification covers unalloyed and alloyed Tantalum Ribbon, Tantalum Alloy Ribbon, Tantalum Strip, Tantalum Alloy Strip, Tantalum Foil, Tantalum Alloy Foil, Tantalum Sheet, Tantalum Alloy Sheet, Tantalum Plate, Tantalum Alloy Plate as follows:
1. ASTM B 708 -05 UNS R05200, unalloyed tantalum, electron-beam furnace or vacuum-arc melt, or both.
2. ASTM B 708 -05 UNS R05400, unalloyed tantalum, powder-metallurgy consolidation.
3. ASTM B 708 -05 UNS R05255, tantalum alloy, 90% tantalum 10% tungsten, electron-beam furnace or vacuum-arc melt, or both.
4. ASTM B 708 -05 UNS R05252, tantalum alloy, 97.5% tantalum 2.5% tungsten, electron-beam furnace or vacuum-arc melt, or both.
5. ASTM B 708 -05 UNS R05240, tantalum alloy, 60% tantalum 40% columbium, electron-beam furnace or vacuum-arc melt.
+++++++++++++++++++++++++++++
Standard Specification for Unalloyed Tantalum for Surgical Implant Applications (ASTM F 560 - 05 UNS R05200, ASTM F 560 - 05 UNS R05400).  This specification is under the jurisdiction of ASTM committee F04 on Medical and Surgical Materials and  Devices (orthopaedic medical devices) and is the direct responsibility of Subcommittee F04.12 on metallurgical Materials.

This Specification covers the chemical requirements, mechanical properties, and metallurgical requirements for unalloyed tantalum wire, unalloyed tantalum rod, unalloyed tantalum tube, unalloyed tantalum ribbon, unalloyed tantalum strip, unalloyed tantalum foil, unalloyed tantalum sheet, unalloyed tantalum plate, etc., used in the manufacture of surgical implants.

Referenced Standards :
ASTM B 364 Specification for Tantalum and Tantalum Alloy Ingots;
ASTM B 365 Specification for Tantalum rod + Tantalum Alloy Rod + Tantalum Wire + Tantalum Alloy Wire;
ASTM B 708 Specification for Tantalum Ribbon, Tantalum Alloy Ribbon, Tantalum Strip, Tantalum Alloy Strip, Tantalum Foil, Tantalum Alloy Foil, Tantalum Sheet, Tantalum Alloy Sheet, Tantalum Plate, Tantalum Alloy Plate;
ASTM E 8 Test Methods for Tension Testing of metallic Materials;
ASTM E 29 Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications;
ASTM F 981 Practice for Assessment of Compatibility of Biomaterials for Surgical Implants with Respect to Effect of Materials on Muscle and Bone;
ASQ C1 Specification of General Requirements for a Quality Program;
